GT14000DJ
High speed Electric police bike GT14000,118v120Ah
Send Inquiry
Download Brochure

GT14000DJ

  • GT14000DJ
  • GT14000DJ
  • GT14000DJ
  • GT14000DJ

Model introduction
Technical parameters

Basic Parameter（基本参数）
Dimension（外形尺寸）2283*1050*1330mm
Wheelbase（前后轮轴距）1570mm
Minimum Ground Clearance（最小离地间距）150mm
Net Weight（净重）315Kg
Max Load（载重）465Kg
Max Speed（最高速度）160Km/h
Max.Traveled Distance（续航能力）200Km
Max.Grade Ability (Angle)（爬坡能力）≥30°
Braking Mode(Front Wheel)（前轮制动模式）320mm双盘式液压，4活塞卡钳
Braking Mode(Rear Wheel)（后轮制动模式）265mm单盘式液压，4活塞卡钳
Manipulation Braking Mode（制动操纵方式）
Front Rim Type（前轮辋型式）铝合金aluminum
Tyre Size（前/后轮胎规格）120/70   ZR17前 180/55 ZR17后
Motor Power（电机功率）24kw
Gear Type（档位型式）6
Max Power（最大功率）45/5000kw/rpm
Max Torque（最大扭距）119/9600Nm/rpm
Rotate Speed（最高转速）
Controller（控制器）
Battery Type（电池类型）锂离子蓄电池lithum battery
Battery Weight（外型尺寸）
Battery Capacity（电池重量）80kg
Charging Time (Hour)（电池容量）14.2kWh  118.4v120AH
Charging Power（充电时间）1.4
Charging Power（充电功率）6.6KW




Specifications of the front tire前轮胎规格120 70 ZR17
Rear tire   specification后轮胎规格180 55 ZR17
Steering Angle (degree)转向角(度)72°
Transmission   system传动系统Three-speed   six-speed transmission
    三级六档变速
Maximum ground clearance (mm)最大离地高度(mm   )150
Motor cooling   method电机冷却方式Circulating water   cooling循环水冷
Rated voltage (V)额定电压（V ）118 4
Crew (person)乘员(人)2
Rated capacity (kW/ h)额定容量( kW/ h)14.2
Rated voltage (V)额定电压（V）118 4
Single battery capacity (Ah)单体电池容量（Ah）  120
Maximum allowable discharge current (A)允许最大放电电流（A ）450/30s
