1

Vehicle

 LxWxH

mm

2137X829X1333

2

 Wheelbase

mm

1400

3

Wheel track

mm

-

4

Min ground clearance

mm

159

5

Curb weight

kg

205

6

Rated passenger capacity

2

7

Brake   type (Front/Rear)

-

Disc/Disc

8

Brake   control mode (Front/Rear)

-

Hand brake/foot brake

9

Rim type   (Front/Rear)

-

One piece light weight alloy/ One piece light weight alloy

10

Tyre size   (Front/Rear)

-

110/70-17/150/60-17

11

Tyre pressure   (Front/Rear)

kPa

280/280

12

 Drive Mode

-

 Belt drive

13

Electric Part

 Motor model

-

155YC-J13060416NA

15

Motor type

-

Permanent magnet synchronous motor

16

Motor operating voltage

V

130

17

Motor   rated torque

N.m(r/min)

16.71N.m

18

Motor   rated power

kW(r/min)

10.5Kw

19

Controller model

-

YCK130160A

20

Battery type

Lithium

HDBAT-1P40S-147.6-2

21

Battery capacity

Ah

73Ah

22

Battery   nominal voltage

V

146

23

Undervoltage   protection value

V

104±4

24

Overcurrent   protection value

A

300±10

25

Charger   input voltage/ frequency

V/Hz

220/50

26

Main parameters

（V200）Max. speed (V200)

km/h

128

27

10min（V10）

10min   Max. speed (V10)

km/h

150

28

Gradeability

(°)

≥20°

29

Driving   range (km)

km

150/180

30

SOC   warning mileage

km

30
